Product Introduction
The pulse flyback transformer, also known as flyback transformer, is a core component in switching power supplies that integrates energy storage and voltage transformation functions. It is widely applied in medium and low-power isolated power supplies. Operating in discontinuous mode, it stores energy when the power switch tube is on and releases energy to the load when the tube is off, thereby realizing voltage conversion.
Product Features
Adopting high-frequency pulse design with a gapped core, it delivers strong anti-magnetic saturation performance.
Optimized winding process ensures low leakage inductance and low power loss, suitable for fully automated production.
Flexible turn ratio design supports multiple output channels.
Diverse product specifications to meet the demands of various application scenarios.
Application Fields
Pulse flyback transformers are mainly applied to:
FAQ
Q: What should be noted for the product to meet safety regulations?
A: Use triple-insulated wire for the secondary winding.
Sleeve all windings with insulating tubes.
Add insulating isolation tape between windings when necessary.
Product Parameters
|
Model No.: |
EE40 |
Withstand Voltage: |
2000V/60S/2mA |
|
Power Rating: |
800W |
Temperature Class: |
Class F |
|
Inductance: |
1.8H±10% |
Turns Ratio: |
47:47:1200:47:47 |
